Minimalistic, but far from basic. Built-in Alexa voice control, DTS®Virtual:X™ virtual 3D surround sound, built-in subwoofers, and a slim profile suited for TV stand or wall placement.
"Alexa*, turn the volume up in the living room."
With Alexa voice control integration, all you have to do is ask. The ATS-1090 offers built-in Alexa voice control for easy control of your sound bar, smart home devices, music and more. Group your ATS-1090 sound bar with other Alexa devices for multi-room audio.
Additionally, a Mute feature ensures your privacy when needed by muting Alexa
Take your home cinema experience to new heights with sound that comes from above as well as all around you.
The ATS-1090 features DTS Virtual:X – immersing the audience in exhilarating 3D surround sound from a single bar solution.
Simply pair your Bluetooth device with the ATS-1090 and start streaming your favorite tunes or video sound wirelessly to your sound bar.
Seamless entertainment. No headaches.
The ATS-1090 is an instant upgrade to your TV sound. Connection is as simple as one cable to the power outlet and another to your TV. With HDMI-CEC, you can even use your TV remote control for added convenience.
Adding to its versatility, the ATS-1090 is at home either sitting in front of a TV on an entertainment unit or mounted on a wall below a TV (no wall-mounting bracket required).
The bass extension feature delivers low frequency effects so explosions have more punch and car engines have more rumble – putting you in the thick of the action.
With the Clear Voice mode enabled, enhanced dialogue clarity means you never have to miss out on that critical scene or plot twist again.
Open the door to a world of music with the ability to access Spotify and Amazon Music directly from the sound bar.
Experience movies, music, gaming, sports and TV shows with incredible 3D surround sound or choose your favorite sound mode.
Connecting your sound bar to your Wi-Fi network enables you to browse and stream music from all your connected smart devices including a PC, laptop, NAS (Network-Attached Storage) or smartphone.
The free Sound Bar Controller app gives you enhanced control in a simple, intuitive design.
ATS-1090 |
|
|
General |
Drivers |
Front L/R: 2-1/8" cone × 2, Tweeter: 1" dome × 2, Built-in subwoofer: 3" cone × 2 |
Output Power |
120 W (Front L/R: 30 W × 2-ch, Built-in subwoofer: 60 W) |
|
Power Consumption |
30 W (Rated), 4.3 W (Voice Control Ready) |
|
Dimensions (W x H x D) |
Installing the unit in front of a TV: 35" x 2-1/8" x 5-1/8", Mounting the unit on a wall with spacers: 35" x 5-1/8" x 2-1/2" |
|
Weight |
7.5 lbs |
|
Input / Output |
HDMI |
1 in / 1 out |
Digital Optical |
1 in |
|
Subwoofer Output |
Yes |
|
HDMI |
4K Pass-through |
Yes (50 / 60 Hz YCbCr=4:4:4, HDR10, HLG and HDCP 2.3) |
4K Pass-through3D Pass-through |
Yes |
|
ARC |
Yes |
|
CEC |
Yes |
|
Auto Lip-Sync |
Yes |
|
Sound Technology |
Virtual Surround Technology |
DTS® Virtual:X™ |
Surround Modes |
Music, TV program, Movie, Sports, Game |
|
Compressed Music Enhancer |
Yes (for Bluetooth) |
|
Bass Extension |
Yes |
|
Audio Formats |
Dolby Digital |
Yes |
Dolby Pro Logic II |
Yes |
|
DTS Digital Surround |
Yes |
|
File Formats |
WAV (PCM format only) / FLAC: up to 192 kHz, ALAC: up to 96 kHz, MP3 / WMA / MPEG-4 AAC: up to 48 kHz |
|
Connectivity |
Built-in music streaming services |
Yes |
Wi-Fi |
Yes (2.4 GHz) |
|
AirPlay |
No |
|
Bluetooth Version/Profile |
Version: Ver 4.2 / Profiles: A2DP, AVRCP / Codecs: SBC, AAC |
|
Bluetooth Maximum Communication Range |
33 ft (without obstructions) |
|
Wireless Subwoofer |
No |
|
Other Features |
App Control |
Yes (Sound Bar Controller) |
